• Power supply: internal rechargeble Ni-Mh batteries
• AC/DC adapter: 100-240V, 50-60 Hz; 200mA
• Battery autonomy: 3 hours
• Applied part: cf type
• Input impedance: > 100 Mohm
• Frequency response: 0.05: 145hz
• Cmrr: > 100 dB time constant: > 3.2 s
• Acquisition: 12 bit 800 samples/sec/channel
• Leads: 12 standard or Cabrera
• Sensitivity: 5mm/mV; 10mm/mV; 20mm/mV ±5%
• Scrolling speed: 5mm/s; 10mm/s; 25mm/s; 50mm/s
• Signal memory: 10 sec for each lead
• Printer: thermal printer 8 dots/mm, paper 58 mm.
• Defibrillation protection: internal
• Filters:
– muscles tremors 35Hz digital;
– power line interferences 50-60Hz digital;
– high pass 0.5Hz digital
• Dimensions: 190 x 120 x 60 mm
• Weight: 1 Kg.
• Conformity standards: 93/42/CEE; EN60601-1;
• EN60601-1-2; IEC601-2-25
• Made in Italy
